CO2 laser dot matrix control system, support customer-specific interface, array mirror can be customized according to customer requirements, support multiple languages: Chinese, traditional, English, Japanese, Russian, Spanish, etc. This array mirror has stable graphics, good heat dissipation effect of the driver board, fast speed, fine spot and stable performance.
| CO2導光臂系列 | ||||||
|
產品型號 Product model |
A款 | B款 | C款 | D款 | E款 | F款 |
|
通光孔徑 Through aperture |
Φ14mm | Φ14mm | Φ14mm | Φ14mm | Φ14mm | Φ14mm |
|
臂展 Maximum spread arm length |
1.5M | 1.5M | 1.5M | 1.5M | 1.5M | 1.5M |
|
關節數 Number of joints |
6關節/7關節 Six joints/Seven joints |
7關節 Seven joints |
7關節 Seven joints |
7關節 Seven joints |
7關節 Seven joints |
7關節 Seven joints |
|
重量 Weight |
4.92kg | 5.29kg | 11.49kg | / | 5.68kg | 10.85kg |
|
反射鏡反射率 Reflector reflectivity |
＞99.6% | |||||
|
反射波長 Reflection wavelength |
可支持波長532、1030、1064、755、785、1550、2940、10600…… Can support wavelengths 532, 1030, 1064, 755, 785, 1550, 2940, 10600 |
|||||
|
損傷閾值 Damage threshold |
＞6J/cm2 | |||||
|
材料 Material |
外部6063鋁合金，內部SUS304不銹鋼 External 6063 aluminum alloy, internal SUS304 stainless steel |
|||||
|
軸承 Bearing |
均采用進口NSK軸承 Imported NSK bearings are adopted |
|||||
|
光斑偏差 Spot deviation |
±0.6MM | |||||
|
外觀 Appearance |
可支持客戶要求定制外觀顏色 Can support customer requests for customized appearance colors |
|||||
|
備注：（重量含包裝箱），如有參數/規格變化另行通知修改 （Weight includes packing), If there is any change in the parameter specification, we will notify you to modify it |
||||||
